Ленточно-шлифовальная машина Qgrind 100

Двухленточная шлифовальная машина Qgrind 100 предназначена для снятия заусенцев и предварительной шлифовки образцов или других материалов.

На ней можно одновременно использовать две различные ленты с различными размерами зерна. Отходы производимые при шлифовке, удаляются путем промывки водой.

Особенности

Easy belt exchange

Both shroud covers are made of stainless steel and are simply opened backwards. This allows free access to the individual belts. Rotate the front tension wheel to loosen the belt which can then be removed from the side. Similarly, by rotating the adjustment wheel, the new belt can be centred onto the middle of the working surface.

Water-cooling

A water film is created over the whole width of the front end of the belt. Waste material generated is carried to the back with the water and both are drained-off into the machine. Drain-offs are separated, one to the left, one to the right

Drive

A powerful motor drives both belts at the same time. The rubber coated drive wheels, which are fitted with a special tread, prevent the belt from slipping.
